ETA level 3 NVQ Diploma in Fabrication and Welding
The NVQ Fabrication and Welding qualification is made up of 3 mandatory units that will help learners to develop an understanding of the knowledge and skills required for the workplace. As such, its mandatory units form a foundation to extend the understanding and skills in specific areas through the optional routes. In addition, learners are required to achieve additional units selected from a suite of 7 Pathways and in accordance with the achievement definition. Moreover, learners who complete the qualification will be equipped with the knowledge and skills to underpin career development within the industry.
Who is this course for?
The NVQ Fabrication and Welding qualification is designed to support those learners training in Fabrication and Welding, however, it is also available for individuals who are not following an apprenticeship. It provides a structured individualised route with knowledge and skills for those who wish to achieve a qualification in Fabrication and Welding Engineering.
How long do I get to complete this qualification?
You are allowed 12 months to complete from registration. In addition, your progress can be monitored in OneFile as we will program your start and finish dates. Consequently, If you do not complete within the given time, you can extend on a month by month basis.
Group A – Mandatory Units: (All 3 must be completed) – All Pathways
- Firstly, Complying with Statutory Regulations and Organisational Safety Requirements (A/601/5013)
- Secondly, Using and Interpreting Engineering Data and Documentation (Y/601/5102)
- Lastly, Working Efficiently and Effectively in Engineering (K/601/5055)
Pathways
Manual Welding – Must complete any one unit from the following:
- Welding Materials by the Manual Metal Arc Process
- Welding Materials by the Manual MIG/MAG and Flux-Cored Wire Processes
- Welding Materials by the Manual TIG and Plasma Arc Welding Process
- Welding Materials by the Manual Oxy/Fuel Gas Welding Process
- Welding Pipe/Tube using Multiple Manual Arc Welding Processes
- Welding Plate using Multiple Manual Arc Welding Processes
Welding Machine Setting and Operating – Must complete two units from the following:
- Resolving Engineering Problems (ETS3.43 from L3 Engineering Technical Support)
- Implementing Engineering Activities (ETS3.45 from L3 Engineering Technical Support)
- Monitoring Engineering Activities (ETS3.46 from L3 Engineering Technical Support)
Plus one more unit from the following:
- Preparing Mechanised Arc Welding Equipment for Production
- Preparing Resistance Spot, Seam and Projection Welding Machines for Production
- Preparing Laser Welding Machines for Production
- Preparing Electron Beam Welding Machines for Production
- Preparing Friction Welding Machines for Production
- Preparing Brazing Machines for Production
Plus one more unit from the following:
- Welding Materials with Mechanised Arc Welding Equipment(FAB2.09 from L2 Fabrication and Welding Engineering)
- Welding Materials using Resistance Spot, Seam and Projection
- Welding Machines (FAB2.10 from L2 Fabrication and Welding Engineering)
- Welding Materials using Laser Welding Machines (FAB2.11 from L2 Fabrication and Welding Engineering)
- Welding Materials using Electron Beam Welding Machines (FAB2.12 from L2 Fabrication and Welding Engineering)
- Welding Materials using Friction Welding Machines (FAB2.13 from L2 Fabrication and Welding Engineering)
- Joining Materials using Brazing Machines
Rail Welding – Must complete one of the following pairs of units:
Either:
- Welding Rails using Aluminothermic Welding Process
- Restore Rails to Operational Condition using an Arc Welding Process
Or:
- Preparing Flash Welding Machines for Operation
- Joining Rails using Flash Welding Equipment
Sheetmetal Working (3mm or less) – Must complete the following units:
- Firstly, Marking Out Components for Metalwork
- Secondly, Cutting Sheetmetal to Shape using Hand and Machine Tools
- Lastly, Forming Sheetmetal using Hand and Machine Tools
Plus two more units from the following:
- Producing Sheetmetal Assemblies
- Heat Treating Materials for Fabrication Activities
- Developing and Marking Out Templates for Metalwork
Plus one more from the following:
- Joining Fabricated Components using Mechanical Fasteners
- Bonding Engineering Materials using Adhesives (FAB2.29 from L2 Fabrication and Welding Engineering)
- Joining Materials by Resistance Spot Welding (FAB2.30 from L2 Fabrication and Welding Engineering)
- Producing Fillet Welded Joints using a Manual Welding Process
- Operating CNC Fabrication Equipment
Plateworking (3mm upwards) – Must complete one unit from the following:
- Marking Out Components for Metalwork
- Developing and Marking Out Templates for Metalwork
Plus one more from the following:
- Cutting Plate and Sections using Shearing Machines
- Cutting and Shaping Materials using Portable Thermal Cutting Equipment
- Cutting Materials using Saws and Abrasive Discs (FAB2.35 from L2 Fabrication and Welding Engineering)
- Operating CNC Fabrication Equipment
Plus two more units from the following:
- Bending and Forming Plate using Press Brakes or Bending Machines
- Forming Platework using Power Rolling Machines
- Producing and Finishing Holes using Drilling Machines
- Producing Platework Assemblies
Plus two more units from the following:
- Joining Fabricated Components using Mechanical Fasteners
- Producing Fillet Welded Joints using a Manual Welding Process
- Slinging, Lifting and Moving Materials and Components
Structural Steelwork – Must complete one unit from the following:
- Marking Out Components for Metalwork
- Developing and Marking Out Templates for Metalwork
Plus one unit from the following:
- Cutting Plate and Sections using Shearing Machines
- Cutting and Shaping Materials using Portable Thermal Cutting Equipment
- Cutting Materials using Saws and Abrasive Discs (FAB2.35 from L2 Fabrication and Welding Engineering)
- Operating CNC Fabrication Equipment
Plus two more units from the following:
- Forming Structural Sections using Machines
- Producing Structural Steel Ancillary Components
- Producing Major Structural Components/Sub-assemblies
- Producing and Finishing Holes using Drilling Machines
Plus two more units from the following:
- Joining Fabricated Components using Mechanical Fasteners
- Producing Fillet Welded Joints using a Manual Welding Process
- Erecting Structural Steelwork
- Slinging, Lifting and Moving Materials and Components
Pipe and Tube Fabrication – Must complete one unit from the following:
- Marking Out Components for Metalwork
- Developing and Marking Out Templates for Metalwork
Plus one more unit from the following:
- Cutting and Shaping Materials using Portable Thermal Cutting Equipment
- Cutting Materials using Saws and Abrasive Discs (FAB2.35 from L2 Fabrication and Welding Engineering)
- Bonding Engineering Materials using Adhesives (FAB2.29 from L2 Fabrication and Welding Engineering)
Plus two more units from the following:
- Forming Pipework by Machine Bending
- Producing Pipe Fabrications
- Producing and Finishing Holes using Drilling Machines
Plus one more unit from the following:
- Joining Fabricated Components using Mechanical Fasteners
- Producing Socket and Flange Fillet Welded Joints in Pipe using a Manual Welding Process
CSCS Card Eligibility
By enrolling on the NVQ Diploma Fabrication and Welding, you can meet one of the requirements to apply for the RED CSCS – TRAINEE card.
See here-> Card Finder (cscsonline.uk.com)
